GARDEN TRACTOR OM 102/21 KH 68129891
- GARDEN TRACTOR OLEO-MAC OM 102/21 KH 68129891 - powerful Emak K2000 engine, hydrostatic drive, 102 cm cutting width, 300 l basket. Ideal lawn mower tractor for lawns up to 4,000 sq. ft.
Garden tractor Oleo-Mac OM 102/21 KH 68129891 is a powerful and reliable lawn tractor-cutter, designed for intensive lawn care of areas up to approx. 4000 m². It combines the high cutting performance, comfort and solid cast iron construction characteristic of the premium line. This is a self-propelled garden mower with hydrostatic drive, designed for mowing, collecting grass into a capacious basket, and optionally also for grinding (mulching) grass.
The tractor is mounted and used directly on home lawns, green areas around houses, recreational plots, residential areas or at service facilities. Thanks to its compact dimensions and small turning radius, the OM 102/21 KH is ideal for use wherever trees, flowerbeds and other obstacles need to be avoided efficiently, yet cutting quality similar to professional machines is expected.
Oleo-Mac OM 102/21 KH garden tractor - powerful Emak K2000 engine and professional cutting system
At the heart of the OM 102/21 KH garden tractor is a modern 635 cm³ Emak K2000 OHV twin-cylinder engine. With an operating power of 11.5 kW at 2,700 rpm, the./min the machine easily copes with dense, tall grass, even on slightly undulating terrain. OHV design (with valves in the head) for efficient combustion, lower fuel consumption, and quieter and cleaner operation.
With a cutting width of 102 cm, realized by two powerful blades, mowing time can be significantly reduced compared to a traditional walk-behind mower. The cutting unit has been developed based on solutions from professional machines - the grass is accurately cut and efficiently transported to the 300-liter basket, which means less frequent emptying breaks.
Cutting height adjustment from 30-90 mm in 7 steps allows you to adjust the lawn to suit your current needs: from a short, presentable carpet around the house, to taller grass on less frequented parts of the plot. As a result, the tractor will be suitable for regular lawn mowing, as well as for the first spring treatments or cleanup after a long period without mowing.
In addition, an ejection channel plug is available as an option for mulching (grinding) the grass. This is especially useful during the period of intensive grass growth - the finely shredded plant matter remains on the surface and acts as a natural fertilizer, reducing the need for additional lawn feeding.
Hydro Gear hydrostatic drive and exemplary maneuverability - full control of the tractor
The OM 102/21 KH garden tractor is equipped with a hydrostatic Hydro Gear transmission, controlled by a pedal. As a result, the operator does not need to shift gears or take his hands off the steering wheel - just gently press the appropriate pedal to smoothly move, accelerate, decelerate or change direction. Such a solution makes it much easier to maneuver between trees, flowerbeds or narrow passages.
The clutch pedal is hydraulically actuated, which minimizes the risk of sudden, uncontrolled speed changes. The machine behaves predictably, and the operator feels confident both during dynamic mowing in large open spaces and during precise maneuvering around curbs, fences or small garden architecture.
Reduced turning radius to 85 cm makes the tractor extremely maneuverable. In practice, this means less backtracking, fewer awkward maneuvers and faster work in gardens with complex layouts. For example, when mowing a lawn between fruit trees or around numerous ornamental plantings, the operator can smoothly go around an obstacle without having to turn around repeatedly.
Thanks to the hydrostatic drive, it is also possible to precisely control the speed when emptying the basket or transport passes. This is a classic solution known from professional machines, which directly translates into comfort, safety and efficiency of work.
Operator comfort and refined control ergonomics
Oleo-Mac OM 102/21 KH garden tractor is designed for frequent, long hours of work in a home environment. The wide entrance to the operator's station makes it easy to get on and off, which will be especially appreciated by users working in stages - for example, mowing the lawn in several parts of the garden, interrupting work for watering, hedge trimming or other maintenance work.
The pedals have been lined with an anti-slip material, which also increases safety when working in wet conditions or just after a rainstorm. Adjustable seat allows you to adjust the position according to the height of the operator, ensuring comfort and correct body position, important for prolonged work. All major levers and control buttons are within easy reach, making operation of the tractor intuitive even for less experienced users.
The grass tank can be emptied directly from the driver's seat, reducing interruptions and increasing comfort. In practice, this means that when mowing large areas, there is no need to get down from the machine - just drive to the desired location, empty the basket from the seat and get back to work.
Acoustic alarm indicating that the garbage can is full prevents clogging of the ejection tunnel. It's a simple but very practical solution - the operator immediately knows when to stop mowing and empty the container, which translates into smoother operation and less downtime due to the need to clean the ejection channel.
Durable, robust premium construction - investment security for years to come
Oleo-Mac garden tractors of the Premium line, which includes the OM 102/21 KH model, are distinguished by their exceptionally robust construction. Their hallmark is the cast-iron front beam, which provides high rigidity and resistance to the stresses that come with working on rough terrain or frequent turns. Such a solution minimizes the risk of frame deformation and extends the life of the machine.
Wide wheels with tires with specially designed tread guarantee a stable ride while minimizing grass compaction and damage as much as possible. As a result, even after the tractor passes over, the mark on the turf is minimal, and the lawn retains an aesthetic, even appearance. This is especially important for the systematic maintenance of representative gardens surrounding houses, boarding houses or office buildings.
The maximum permissible slope on which the tractor can move is 10° (approx. 17%), which means that the machine also handles well on slightly sloping terrain - such as slopes at the driveway, gentle hills in the garden or differences in level on the plot of land. The total weight of the machine is 254 kg, which translates into machine stability and confident handling.
The AGM 12 V / 28 Ah battery used ensures reliable starting of the engine, even after prolonged downtime. The model is also equipped with an operating hour meter, which makes it easier to schedule periodic services - a simple tool to take care of the machine's condition and avoid unplanned downtime during the season.
Easy operation, simple maintenance and practical additional functions
The OM 102/21 KH garden tractor is designed to make daily operation and basic maintenance as time-consuming as possible. Service operations on the cutting unit are quick and easy - access to the blades and working elements is facilitated, allowing for efficient cleaning, checking the condition of the blades or replacing them as needed.
There are quick couplings on the cutting unit for connecting a water hose. As a result, the entire interior of the unit can be rinsed out quickly and effectively after use - just plug in the cord, run the blades, and rinse out the housing. Regular cleaning prevents grass residue buildup, improves cutting quality and extends the life of the machine.
The blades are activated by the operator using the electromagnetic clutch button located on the dashboard. This system guarantees precise and smooth blade engagement, without the risk of jerks or kickbacks, which improves operational safety and protects transmission mechanisms.
Included with the tractor is a tow hook, which expands the machine's range of applications. It allows you to hook up a garden trailer or other accessories - in practice, the OM 102/21 KH can be used not only for mowing, but also for transporting soil, fertilizer, tools or green waste on the property. This makes the tractor a year-round helper in the garden, not just a seasonal mower.
For transportation reasons, some components (e.g. basket, handlebars, seat) are not assembled at the factory and require assembly after unpacking. Detailed installation instructions can be found in the product documentation. For those without experience, this task can be time-consuming, so consider using an authorized service center that can prepare the machine for operation.
Use of garden tractor OM 102/21 KH in daily garden care
Oleo-Mac OM 102/21 KH garden tractor was created for users who value convenience, time saving and professional lawn care results. It will work perfectly:
- in home gardens of up to approx. 4,000 sq. m, where a classic petrol mower is already too time-consuming;
- on large recreational plots and areas around summer cottages, where we often mow varied sections of land - clearings, drives, recreation areas;
- in the gardens of guesthouses, hotels, restaurants and service facilities, where an aesthetically pleasing lawn is an important part of the corporate image;
- in residential areas, at terraced houses, housing communities, where it is necessary to regularly take care of common green zones;
- in households where, in addition to mowing grass, the tractor is also used for light transportation work thanks to the tow hook.
With its combination of large working width, capacious basket, convenient controls and sturdy construction, the OM 102/21 KH significantly speeds up all mowing and garden cleanup work. It's an investment that pays off in the form of saved time, less physical effort, and an always neat, evenly mowed lawn.
Technical data of garden tractor OM 102/21 KH 68129891
| Engine | Emak K2000 OHV 635 cm³; two cylinders |
| Working power | 11.5 kW at 2700 min-¹ |
| Drive | hydro Gear hydrostatic, pedal controlled |
| Cutting width | 102 cm; two knives |
| Cutting height adjustment | 30-90 mm, 7-stage, spring-assisted |
| Features | collecting into the garbage can, grinding as an option (ejection channel plug) |
| Basket capacity | 300 l |
| Fuel tank | 7 l |
| Wheels | front 15x6.00-6 / rear 18x8.5-8 |
| Turning radius | 85 cm |
| Dimensions (without basket) | 248 x 105 x 112 cm |
| Weight | 254 kg |
| Supply voltage | aGM 12 V / 28 Ah battery |
| Driving on the slopes | up to 10° (approx. 17%) gradients |
| Hour counter | yes |
| Towing hook | included |
Warranty terms and conditions include m.in.:
- 36 months for consumer purchases (with mandatory paid maintenance before 12 and 24 months for the 36-month warranty),
- 12 months for non-consumer purchase.
FAQ - Frequently asked questions about OM 102/21 KH garden tractor
Is the OM 102/21 KH garden tractor suitable for my garden?
This model is ideal for gardens up to approx. 4000 m². It will work well on both home lawns and larger recreational plots, especially where there are obstacles that require frequent maneuvering.
Can the tractor work on sloping terrain?
Yes, the manufacturer allows operation on slopes of up to 10° (approx. 17%). This allows you to safely mow gentle slopes and uneven terrain, while maintaining safety and common sense.
Is the grass only collected in the trash, or can it also be milled?
As standard, the tractor collects grass into a 300-liter basket. As an option, it can be equipped with an ejection channel plug, which allows you to grind (mulch) the grass and leave it on the lawn as a natural fertilizer.
Is it complicated to assemble the tractor after delivery?
For transportation reasons, some components, such as the basket, steering wheel and seat, are delivered disassembled. Step-by-step installation instructions are included with the product. For those without experience, it is recommended to take the help of a service center to prepare the tractor for operation.
What are the main advantages of the hydrostatic drive in this model?
Hydro Gear pedal-controlled hydrostatic drive allows you to smoothly adjust travel speed and easily change direction without shifting gears. This increases comfort, makes it easier to maneuver in tight spaces and improves safety, especially when making frequent turns and working around obstacles.
How to take care of a cutting unit to make it last as long as possible?
After each mowing, it is a good idea to flush the cutting unit with a hose connected to the quick couplings located on the unit. Regular cleaning, periodic inspection and sharpening of knives, as well as performing maintenance according to the manufacturer's recommendations will ensure high quality cutting and long machine life.
WARRANTY TERMS AND CONDITIONS
For warranty terms and conditions, please refer to the instruction manual included in the device packaging. Devices covered by the extended warranty (3 and 5 years) require the execution of the mandatory warranty inspections (payable) at the times specified in the warranty terms and conditions.
The obligations of the guarantor under the guarantee are to repair the defective goods, the advertised device is not subject to replacement or cash back.
1. The manufacturer guarantees its products for a period of time:
- Oleo-Mac internal combustion mowers 60 months for consumer use and 12 months otherwise
- Oleo-Mac chainsaws, Oleo-Mac scythes, Oleo-Mac electric mowers, Oleo-Mac trimmers
TR 61 E and TR 91 E, garden tractors. EMAK K-series internal combustion engines powering mowers and
tractors 36 months for consumer use and in other cases 12 months
- Other devices for consumer use 24 months and in other cases 12 months
Additional consumer warranty on Briggs&Stratton engines after the expiration of the manufacturer's warranty period of 12 months -
The condition for maintaining the 36-month warranty period is to perform two paid inspections of the device at an authorized service center - in 12 and 24 month from the date of purchase no later than 7 days after the specified date.
As a condition for maintaining the 60-month warranty period, four paid inspections of the device must be performed at an authorized service center - at 12, 24,36 and 48 months from the date of purchase no later than 7 days after the appointed date. All inspections performed by the dealer must be recorded in the electronic
b2B guarantee settlement system. Internal combustion engines of other brands (Briggs & Stratton, HONDA, KAWASAKI, SUBARU, etc.).) and hydrostatic transmissions are covered by a separate warranty manufacturer. Details of the warranty terms and conditions are contained in separate manuals for the listed components.
2. The warranty covers all damages occurring during the warranty period resulting from the discovery of latent material defects during this period, assembly or technological.
3. The technical staff will proceed with the repair in the time allowed by organizational requirements, always as soon as possible.
4. The choice of how to remove the damage is up to the guarantor, who can remove the defect by repairing the device or replacing the damaged part. Regardless
way of removing the damage, the warranty continues, extended by the time of removal of the damage by the guarantor.
5. Warranty repair can only be carried out on the basis of the device registration in the B2B system or a valid warranty card with proof of purchase.
Failure to register the device, the warranty card or its cancellation will exclude the guarantor's liability under the warranty provided.
6. The user has the right to appeal against the decision of the service point regarding the qualification of the reported failure. The appeal must be submitted only in the form of in writing with a set of documents stating the course of repairs made and a description of the technical condition of the equipment at the time of the original inspection made by the service point.
7. The warranty period is extended by the time necessary for warranty repair. The dates posted on the claim in the b2B electronic guarantee settlement system.
8. The repair shop is required to make entries regarding the scope of warranty repairs in the B2B electronic warranty billing system.
9. For paid repairs performed, the guarantor provides a 3-month warranty on the condition that the repair is carried out in the guarantor's workshop and that the repair is used for the repair original spare parts. The basis for the claim is the proof of purchase of parts and the service performed.
10. Warranty repair is not subject to: damage caused by improper operation, damage caused by using the device for purposes for which it is not intended, damage caused by the use of improper consumables, mechanical damage, and
caused by improper transportation or storage, damage caused by lack of maintenance, components that have suffered wear and tear in service during proper operation.
11. The warranty is voided as a result of structural changes or modifications made by the user, as a result of interference found by the service point
inside the device by unauthorized persons, as a result of breaking or dismantling the carburetor adjustment locks, in the event that entries are found to have been made in the warranty card by unauthorized persons.
12. The warranty does not cover consumable items and items that wear out during the warranty period, such as:
- Consumable components, e.g.: cutting blades, discs, cutting bars, vee heads, filters, starter cables, spark plugs, bulbs, wheels, drums and clutch jaws,
clutches and friction discs, drive belts, safety bolts, cutting chains and guides, high-pressure washer lances.
- Engine components: cylinders, pistons, rings, crankshaft, bearings, pan, carburetor diaphragms.
- Other consumable parts: knife hubs, safety keyways, shock absorbers, bearings, pan, gears, overload fuses, carbon brushes, control ties and cables
- Starting batteries used in machines with an electric starter
- Components not mentioned in these warranty conditions , which obviously wear out during operation, transportation and storage (such as coating painting).
13. Warranty repair does not include installation, adjustment and maintenance activities.
14. Damage such as engine seizure, bent or cracked crankshaft, broken magnet wheel keyway or knife hub are not repairable warranty.
15. If the service center does not fulfill its obligations, the user is obliged to inform the guarantor of this fact. Refusal to comply repair by the service center must be entered in the warranty card. If the guarantor does not recognize the repair as a warranty repair, the cost of repair and transport is covered by the claimant.
16. Defective spare parts replaced under warranty repair are the property of the guarantor.
17. Complaint should be reported to the nearest authorized service center or directly to the guarantor. Reporting a complaint at the point of sale may cause an increase in repair time.
18. During the reception of the device after warranty repair, it is his duty to make sure that the received device is complete and undamaged. The repair point has the obligation to start the device before handing it over to the user after repair.
19. The service point has the right to charge a fee for performing maintenance activities that are the responsibility of the user and require them to be performed before the proceeding with the repair. The repair shop is obliged to replace, at the user's expense, all components that ensure the safety of the work, which have been damaged damage during operation regardless of the consent of the user.
20. A continuously updated list of service points can be found at www.victus.en
21. The warranty for the goods sold does not exclude, limit or suspend the buyer's rights under the warranty provisions for defects in the goods sold.
22. The cost of an unjustified complaint is paid by the complainant.
23. This warranty is valid in the territory of the Republic of Poland.
24. Any damage caused during transport should be immediately reported to the carrier under penalty of voiding the warranty.
25. The warranty does not cover possible damages caused directly or indirectly to persons or things due to defects in the device or resulting from prolonged downtime in the operation of the device.
