GARDEN TRACTOR OM 92/21 KH 68129890
- Garden tractor OM 92/21 KH 68129890 - powerful Emak K2000 engine, hydrostatic drive, 92 cm cutting width, 300 l basket. Ideal tractor for mowing large lawns up to 4000 m².
GARDEN TRACTOR OM 92/21 KH 68129890 is an advanced, premium self-propelled garden tractor designed for fast and convenient mowing of lawns up to approx. 4000 m². Equipped with a powerful 635 cm³ Emak K2000 OHV engine with two cylinders, hydrostatic foot drive and wide cutting units, it combines high performance, operator comfort and years of durability. It's the ideal choice for homeowners, residences, businesses and green space managers who want reliable performance in and out of season.
The garden tractor is mounted and used directly on the lawn - the operator occupies a comfortable, adjustable seat and controls the machine using the steering wheel and pedals. Thanks to its compact design and small turning radius, the device copes well between trees, flowerbeds, hedges or elements of small garden architecture. Uses for the tractor include mowing and collecting grass into a large basket, optional grass grinding (mulching), and the ability to tow lightweight trailers and accessories (tow hook included).
Mower OM 92/21 KH
Oleo-Mac garden tractors of the Premium line are distinguished from others, first of all by their solid construction (their hallmark is the cast iron front beam), excellent cutting and collecting system and multifunctionality. Thanks to the possibility of using a number of attachments (this applies especially to OM106/124 models), these mowers will find their use all year round.
Rugged yet compact and maneuverable riding mowers. Ideal for frequent use in a domestic environment, in medium-sized areas (up to about 4,000 sq m).) Designed with the same technological solutions , as in models for professional use, combine excellent performance and comfort, making work a pure pleasure.
- Hydro Gear pedal-operated hydrostatic transmission without having to take your hands off the wheel for greater machine control and safety.
- The clutch pedal is hydraulically actuated to reduce unexpected and dangerous speed changes.
- Maximum operator ergonomics thanks to a wide entry, pedals lined with non-slip material, adjustable seat, and a set of buttons and control levers located within easy reach.
- The grass tank can be emptied directly from the driver's seat.
- Maintenance operations on the cutting disc are simple and quick. The wide wheels have specially designed treads that do not damage the grass on which the mower rides.
- Speed is adjusted using a double pedal acting directly on the hydrostatic drive. With this solution, you can change the direction of travel and control the speed of travel also when emptying the basket.
- The blades are activated by the operator by pressing the electromagnetic clutch button on the dashboard. This system always guarantees precise actuation of the blades without the risk of kickback.
- The 7-stage height adjustment system of the cutting unit is controlled by a spring for effortless raising and lowering with a convenient lever.
- Water line connection system by means of quick couplers located on the cutting unit: they guarantee quick effective cleaning of the entire cutting unit.
- Acoustic alarm indicating that the garbage can is full, preventing clogging of the ejection tunnel.
- Reduced turning radius makes it easier to move around plants and ornamental shrubs without unnecessary and cumbersome reverse gear maneuvers or having to reposition the tractor.
- Towing hook supplied with the unit.
Note!
For storage and transportation reasons, some components of the mower are not assembled at the factory (e.g. basket, handlebar, seat) and must be installed after unpacking. For detailed installation information, please refer to the instructions, which can be downloaded from the product page.
For those without experience, such machine assembly can be a time-consuming and difficult task. To avoid possible problems, we recommend contacting a service center that works with us.
*Warranty conditions include: - 36 months for consumer purchase - 12 months for non-consumer purchase.- the need for paid inspections before 12 and 24 months( in the case of 36 month warranty).
Technical specifications:
| Engine | Emak K2000 OHV 635cc; two cylinders |
| Drive | hydrostatic |
| Weight | 231 kg |
| Voltage | aGM battery 12V / 28 Ah |
| Cutting width | 92 cm; two knives |
| Cutting height adjustment | 30-90mm |
| Wheels | front 15x6.00-6 / rear 18x8.5-8 |
| Dimensions | 248x95x112 cm (without basket) |
| Garbage can | 300 l |
| Features | collection |
| Turning radius | 65 cm |
| Fuel tank | 7 l |
| Working power of the tractor | 11.5 kW at 2700 rpm |
| Driving on the slopes | with a slope of up to 10o (17%) |
| Hour counter | yes |
| Grinding | optional ejection channel plug |
Powerful Emak K2000 engine and hydrostatic drive - the heart of the OM 92/21 KH garden tractor 68129890
The highlight of the OM 92/21 KH garden tractor 68129890 is the 635 cm³ Emak K2000 OHV engine with two cylinders. This design ensures high operating culture, even power development and less vibration felt by the operator. Operating power 11.5 kW at 2700 rpm./min allows efficient mowing of lush, taller grass as well - without the risk of "throttling" of the drive unit. In practice, this means that with a single pass you can quickly clean up a large lawn next to a house, on a recreational plot or around a company's headquarters.
The pedal-operated Hydro Gear hydrostatic drive makes driving this tractor similar to driving a car with an automatic transmission. No need to change gear ratios - just press the appropriate pedal to smoothly accelerate, decelerate or change direction. This is a huge advantage in everyday use: when avoiding trees, posts, sliding down gentle slopes or maneuvering around driveways and garden paths.
A turning radius of only 65 cm allows for precise execution of tight curves, which in practice reduces the need for reversing. This reduces mowing time on properties with complex layouts, numerous obstacles or narrow passes. The 7-liter fuel tank ensures long working hours without frequent refueling breaks, which will be especially appreciated by users mowing larger acreages.
92 cm cutting system with two blades - fast mowing and perfect grass collection
Cutting width of 92 cm with two blades allows to cover large areas very quickly. Each pass of the OM 92/21 KH garden tractor 68129890 covers a wide strip of lawn, which significantly reduces working time compared to classic push mowers. Cutting height adjustable on a 7-stage scale (30-90 mm), assisted by a spring that makes it easier to lift the unit, allows you to perfectly adjust the length of the grass to suit your current needs - from a low, representative "carpet" to higher turf in less-traveled areas.
The tractor is equipped with an advanced grass collection system into a large 300-liter basket. Such a capacious tank minimizes the number of emptying breaks, which is important when mowing long strips around single-family homes, commercial buildings or recreational areas. In addition, the filling of the basket is indicated by an acoustic alarm - the operator does not have to dismount every now and then to check the filling level. This is convenient especially when mowing on sunny days, when the grass may be dry and light, but quickly fills the basket.
The blades are activated by an electromagnetic clutch located on the dashboard. One push of a button is all it takes to safely and precisely turn the cutting system on or off, without the risk of a sudden "bounce" or jerk of the drive. For the user, this means greater safety and the ability to easily interrupt mowing, for example, when driving over gravel, paving stones or when maneuvering between flower beds.
Optional ejection channel cap allows the use of the grass grinding (mulching) function. The shredded turf is evenly distributed over the surface of the lawn and acts as a natural fertilizer. This is ideal for gardens where healthy, green turf is a priority without the need for large amounts of fertilizers.
Working comfort and user safety - the ergonomics of the OM 92/21 KH garden tractor
Working with the OM 92/21 KH garden tractor 68129890 is designed to make even longer mowing comfortable and safe. The wide entrance to the operator's station allows for comfortable ingress and egress, which will be appreciated by both the elderly and users who use the machine in work clothes. The pedals have been covered with an anti-slip material for increased safety on rainy days or when working on slightly wet terrain.
Adjustable seat allows both shorter and taller users to adjust the distance to the handlebars and pedals. This makes it easier to maintain the correct position behind the wheel, which reduces back and leg fatigue during mowing sessions of several minutes or more. All buttons and control levers are within easy reach, making it easy to operate even for those without much experience with garden machinery.
A hydraulically controlled clutch pedal eliminates sudden, dangerous speed spikes, and wide wheels with tread designed not to damage turf keep the lawn aesthetically pleasing. The tractor can work on slopes of up to 10° (approx. 17%), which allows you to safely mow gentle slopes, garage exits or gentle hills on the plot.
Premium durable construction - an investment in long-term reliability
Premium line garden tractors are distinguished by their robust, well-thought-out design. The distinctive cast-iron front beam provides exceptional strength to the entire frame and greater resistance to stress when working on uneven ground, climbing curbs or negotiating ruts. The unladen weight of 231 kg testifies to the use of strong, durable components, so that the machine adheres better to the ground and behaves more stably while driving.
Wide wheels with properly designed tread protect the grass from uprooting and the formation of ruts, while guaranteeing good traction on various types of ground - from short turf to slightly softer soil. The cutting unit is designed to make service operations - cleaning, blade inspection, maintenance - simple and quick. In addition, there are quick connectors on the cutting unit for connecting water, which makes it convenient to wash the entire unit after work.
The machine is equipped with an operating hour meter, making it easy to schedule periodic maintenance or oil changes. With a consumer purchase, a 36-month warranty is available (with paid maintenance before 12 and 24 months), and with a non-consumer purchase, 12-month protection is available. This further increases the feeling of safety and confirms the high quality of the tractor's workmanship.
Versatile use in the garden - mowing, collecting and hauling
GARDEN TREATER OM 92/21 KH 68129890 will prove itself wherever speed and convenience of green care counts. It is most often used for regular mowing of home lawns, allotment gardens, areas around hotels, guesthouses, restaurants, sports facilities or service companies. Large 300-litre basket and efficient grass suction system guarantee a clean, aesthetically pleasing turf finish without leaving a swath behind.
With a tow hitch as standard equipment, the tractor can also be used as a small tractor for auxiliary work. You can hook up a lightweight garden trailer to it and carry soil, bark, fertilizer, tools or green waste. In the autumn season, it will be perfect for carrying accessories for collecting leaves, and in winter - when retrofitted with the appropriate attachments - it can help clear snow from paths or the driveway.
The ability to drive on slopes of up to 10° allows work on most typical plots, including those located on slight hills. This makes the OM 92/21 KH tractor a versatile tool that can be used almost all year round, not just during peak mowing season.
FAQ - frequently asked questions about OM 92/21 KH garden tractor 68129890
1. For what area of lawn the OM 92/21 KH tractor is designed?
The OM 92/21 KH is designed for regular mowing of areas up to approx. 4000 m². With a cutting width of 92 cm and a large basket of 300 l, it will be perfect for large home plots and around commercial buildings.
2. Is the tractor suitable for working on inclines?
Yes, the machine can safely operate on slopes of up to 10° (approx. 17%). On steeper inclines, it is advisable to take special care or use other equipment.
3. How the cutting knives are switched on in this model?
The knives are actuated by an electromagnetic clutch - just press a button on the dashboard. This system guarantees precise, smooth blade engagement without the risk of sudden jerking.
4. Does the tractor have a mulching function (grinding the grass)?
Yes, mulching is available as an option. Simply use the ejection channel cap so that the shredded grass is distributed over the surface of the lawn and acts as a natural fertilizer.
5. How the grass catcher is emptied?
The 300-liter bin can be emptied directly from the operator's seat. An audible alarm lets you know when it is full, which prevents clogging of the ejection tunnel and allows you to work without interruption to check the contents.
6. Is it complicated to assemble the tractor after delivery?
For transportation reasons, some components, such as the basket, handlebars and seat, may require assembly after unpacking. For those without experience, it is recommended to take the help of an authorized service center or a point of cooperation with the seller to be sure that the machine is assembled correctly.
7. What are the warranty terms for this model?
A 36-month warranty is provided for consumer purchases, while a 12-month warranty is provided for non-consumer purchases. The condition for maintaining the 36-month warranty is m.in. performing paid inspections before 12 and 24 months of use.
8. What additional work can the OM 92/21 KH tractor be used for??
In addition to mowing and collecting grass, thanks to the tow hook, the tractor can pull a light trailer or other garden accessories. It will work well for transporting soil, compost, wood, tools, and when retrofitted with additional attachments, it can also be used outside the mowing season.
