APACHE 85 2WD MULCHING MOWER 68129242
- Apache 85 2WD mulching mower 68129242 - compact tractor for tall grass, weeds and waste land. Emak K2000 V-Twin 635 cm³ engine, Tuff Torq K46 hydrostatic drive, 85 cm mowing width, ideal for slopes and difficult terrain.
APACHE 85 2WD MULCHING MOWER 68129242 - PROFESSIONAL MULCHING MOWER FOR TOUGH TERRAIN
Apache 85 2WD mulching mower 68129242 is a compact, self-propelled mulching mower for special tasks - ideal for mowing tall, overgrown grass, thick-stemmed weeds and unkempt green spaces. It combines a powerful Emak K2000 V-Twin engine, Tuff Torq K46 DE hydrostatic drive and an 85 cm single-rotor cutting unit, making it perfect for wherever classic garden mowers can no longer cope. The machine is designed for intensive private use, in challenging areas, slopes and areas with limited travel space.
Apache 85 is a modern, compact machine designed for easy transport and use in areas with limited space (wickets, narrow passages). Despite its small size, it retains the cutting quality of classic mulchers, although it is not designed for commercial work and daily intensive work. It features an optimal balance between performance and mobility - a powerful cutting mechanism in a compact form.
This mower works well in demanding terrain, where it will have to deal with uneven terrain, a sizable slope and vegetation with thick stems and a height of more than a meter.
Apache 85 2WD mulching mower - what is this machine and where it is used?
The Apache 85 2WD mulching mower is a self-propelled mulching tractor that dumps finely shredded grass directly onto the ground instead of a traditional basket. The resulting layer of mulch protects the soil from drying out and enriches it with nutrients. This makes the Apache 85 2WD ideal for regular maintenance of demanding green spaces where the priority is to keep things tidy, not to pick up swaths.
The machine has been designed to work in hard-to-reach places - wherever the entry of a classic tractor is difficult. Compact dimensions (length 194 cm, overall width 94 cm, height 106 cm) and single-rotor aggregate 85 cm allow for easy maneuvering between trees, posts or fences, as well as passage through narrow wickets and isthmuses.
Practical application:
- keeping tall grass and volunteer trees in check on recreational and habitat plots,
- care of the shoulders of internal roads, access roads and paths on the property,
- mowing of wastelands, orchards, overgrown field edges and meadows,
- cleaning work in the areas around guesthouses, agritourism farms or small service facilities.
The Apache 85 2WD assembles and uses like a classic garden tractor - the operator takes a seat, operates the machine using the steering wheel, pedals and levers, and the modular design makes it easy to fit into a garage or shed space. The mower does not need to be hitched to a tractor - it is self-propelled and completely independent in operation.
Maximum mulching capacity in a compact form
At the heart of the Apache 85 2WD mulching mower is a single-rotor cutting unit with a width of 85 cm, equipped with two free blades. This design ensures effective shredding of plants over one meter tall, including weeds with thick, woody stems. The mulch is evenly distributed over the surface, reducing clogs and unevenness on the mowed area.
Cutting height adjustment of approx. 40-90 mm (5 positions) is done by a convenient lever with memory lock. A power-assisted spring makes raising and lowering the cutting unit effortless even during prolonged operation. This allows you to select the mowing height to suit current conditions:
- lower setting - for regular maintenance of utility areas,
- higher - for the first mowing of heavily overgrown wastelands or meadows.
The blades are actuated by an electromagnetic clutch with a button on the dashboard. This system ensures that the cutting drive is engaged precisely and securely without the risk of a sudden "jerk" or kickback. This is not only a convenience for the operator, but also a longer life for the entire system and less strain on the engine.
Examples of benefits in daily use:
- effective cleanup of areas that have been mowed sporadically or not at all,
- quick preparation of the plot for investment, fencing or recreation,
- regular mulching of roadsides and ditches where traditional rotary mowers fail.
Emak K2000 V-Twin 635 cm³ engine - power and reliability in difficult terrain
The Apache 85 2WD mower is powered by a powerful 635 cm³ Emak K2000 V-Twin twin-cylinder engine. V-Twin design ensures work culture, less vibration and high durability under long-term load. The working power of the tractor is 12 kW at 3000 rpm./min, which translates into stable, smooth mowing even in dense vegetation and at steeper slopes.
Large, 10-liter fuel tank with a level indicator visible from the operator's seat guarantees long working hours without frequent refueling breaks. This is crucial when mowing larger acreages - you can plan your work and use every hour efficiently.
User benefits:
- reliable firing and stable operation even under heavy mulching loads,
- less operator fatigue due to reduced vibration of the drive unit,
- lower risk of service downtime - thoughtful, durable engine design.
The machine has been adapted for safe operation on slopes of up to 18° (approx. 33%). The low center of gravity and properly adjusted wheelbase (front/rear 69/67 cm) increase stability on inclines, which is of great importance when maintaining slopes, embankments or drainage ditches.
Tuff Torq K46 DE hydrostatic drive - full speed and direction control
The Apache 85 2WD mower is equipped with the renowned Tuff Torq K46 DE hydrostatic drive with automatic differential. The hydrostatic transmission is controlled by a pedal, so the operator does not have to take his hands off the steering wheel. This configuration increases machine control, improves safety and facilitates precise maneuvering in tight spaces.
The maximum operating speeds are:
- up to 8.5 km/h forward - efficient movement between workstations,
- up to 4.5 km/h in reverse - convenient reversing and correction maneuvers.
The clutch pedal is hydraulically controlled, reducing the risk of a sudden, unexpected change in speed. Reduced turning radius makes it easier to avoid trees, ornamental shrubs, flowerbeds and other obstacles without having to use reverse gear repeatedly.
Examples of applications where hydrostatic drive gives an advantage:
- mowing around outbuildings, fruit trees and fence posts,
- maneuvering on narrow exits, between buildings, along fences,
- precise access on slopes and near ditches, where a smooth change of speed is required.
Ergonomics and operator safety during long operation
Apache 85 2WD is designed to make the operator's work as comfortable and safe as possible. Wide entrance, metal non-slip floor and adjustable seat ensure a comfortable position even when mowing for long hours. All important buttons and control levers are within easy reach, allowing intuitive operation of the machine without bending or taking your eyes off the work area.
Low center of gravity increases stability on slopes and minimizes the risk of tipping over. Robust wheels with all-terrain tires (front 13"×5"-6", rear 16"×6.5"-8") provide good grip both on grass and softer ground.
Examples of situations where ergonomics is critical:
- mowing vast, undulating meadows - the operator spends several hours on the machine,
- work in hot weather, where seating comfort and ease of use affect safety,
- frequent maneuvering around obstacles when quick and precise reactions are essential.
Durable design, towing capability and years of trouble-free operation
A sturdy underframe, metal working deck and high-quality mechanical components make the Apache 85 2WD an investment for years to come. The use of steel elements at key points in the structure increases resistance to impacts, accidental snagging on stones or uneven terrain. Total weight of 249 kg provides adequate ground pressure, improving stability and mowing quality.
The mower has a towing function - a tow bar is provided at the factory (optional, code: OB-ACCS532986013283). This allows the machine to be used not only as a mulcher, but also as a small tractor for transporting garden trailers, carts or spreaders. This is especially useful on larger properties, farms and landscaping companies.
Warranty terms and conditions (for selected markets) include m.in.:
- 36 months for consumer purchases,
- 12 months for non-consumer purchases,
- the need for paid inspections before 12 and 24 months (for 36-month warranty).
For transportation and storage reasons, some components of the mower (e.g., basket - if present in the configuration, handlebar, seat) may not be assembled at the factory and must be assembled after unpacking. Detailed installation instructions are available in the product documentation. For those without experience, it is recommended to use the services of an authorized service provider working with the seller.
Technical specifications of Apache 85 2WD mulcher mower 68129242
Key technical data is summarized below to make it easier to compare the Apache 85 2WD with other machines and to select equipment for working conditions:
| Drive | Tuff Torq K46 DE hydrostatic transmission (rear) with automatic differential |
| Engine | Emak K2000 V-Twin, 635 cm³; two cylinders |
| Working power | 12 kW at 3000 rpm./min |
| Cutting width | 85 cm, single-rotor with 2 free blades |
| Cutting height adjustment | about. 40-90 mm (5 positions) - lever control with spring and memory lock |
| Weight | 249 kg |
| Overall dimensions | length 194 cm × height 106 cm × width 94 cm |
| Wheels | front 13"×5"-6", rear 16"×6.5"-8" |
| Driving on the slopes | recommended slope up to 18° (33%) |
| Front/rear wheelbase | 69 / 67 cm |
| Maximum speeds | up to 8.5 km/h (front), up to 4.5 km/h (rear) |
| Fuel tank | 10 l, level indicator visible from the operator's seat |
| Additional features | towing capability (hook optional), electromagnetic clutch of blades, compact design for working in narrow passages |
Key benefits of choosing an Apache 85 2WD mulcher mower
- Professional mulching of difficult areas - tall grass, weeds, volunteer trees and overgrown slopes are not a problem. The machine effectively shreds and leaves a tidy, no need to rake the swath.
- Compact size while maintaining high power - Easy transportation on a trailer, entry through narrower gates and wickets, yet high mowing performance thanks to 85 cm width and V-Twin motor.
- Safety and comfort - Low center of gravity, comfortable seat, hydrostatic drive, precise steering and ergonomic layout of controls.
- Versatility of applications - From private plots of land to farms and agro-tourism, from wasteland to the sides of access roads and paths.
- Expandable functions - An optional tow hitch allows you to turn the Apache 85 into a small tractor for a wide variety of support work on the property.
FAQ - Frequently asked questions about the Apache 85 2WD mulching mower
Question 1: What type of terrain is the Apache 85 2WD mulcher mower best suited for??
Apache 85 2WD is designed mainly for difficult and neglected areas - wastelands, meadows, field edges, slopes, ditches, roadsides of internal roads and recreational plots with high grass and weeds. Works well where the classic garden mower has problems with the height and density of vegetation.
Question 2: Is the Apache 85 2WD mower suitable for daily commercial use?
The machine retains the cutting quality typical of mulchers, but is not designed for intensive, multi-hour commercial work day in and day out. It is ideal for demanding private users, smaller businesses and areas where regularity of mowing is high but not daily.
Question 3: What slope can be safely mowed with this mower?
Apache 85 2WD is suitable for slopes up to about 18° (33%). This translates into safe operation on typical slopes next to roads, embankments or low elevations on the property. Always follow the instructions in the manual and use caution.
Question 4: Is a lot of experience needed to operate the mower?
Operation is intuitive thanks to the hydrostatic drive, simple steering and ergonomic position behind the wheel. However, the first assembly of components (such as a seat or steering wheel) and the commissioning of the machine can be a challenge for those without practice. In this case, it is recommended to use the assistance of an authorized service partner of the seller.
Question 5: Does the mower collect the grass into a basket?
Apache 85 2WD is a typical mulching mower - it doesn't collect grass into a garbage can. Vegetation is shredded and left on the ground as a natural mulch. This solution speeds up the work, eliminates the need to empty the basket and improves the condition of the soil.
Question 6: What are the warranty requirements?
Up to 36 months warranty on consumer purchase and 12 months on non-consumer purchase as standard (details may depend on market and vendor). Paid inspections are required before 12 and 24 months to maintain the 36-month warranty. For exact terms and conditions, please refer to the warranty card.
Question 7: Can the Apache 85 2WD pull a trailer?
Yes, the design provides for the installation of a tow bar (available as an option). After its installation, the mower can be used as a small tractor for towing garden trailers, spreaders or other light attachments.
The Apache 85 2WD mulching mower 68129242 is the ideal choice for those who want a combination of compact size, high power and professional quality mulching in one reliable machine.
WARRANTY TERMS AND CONDITIONS
For warranty terms and conditions, please refer to the instruction manual included in the device packaging. Devices covered by the extended warranty (3 and 5 years) require the execution of the mandatory warranty inspections (payable) at the times specified in the warranty terms and conditions.
The obligations of the guarantor under the guarantee are to repair the defective goods, the advertised device is not subject to replacement or cash back.
1. The manufacturer guarantees its products for a period of time:
- Oleo-Mac internal combustion mowers 60 months for consumer use and 12 months otherwise
- Oleo-Mac chainsaws, Oleo-Mac scythes, Oleo-Mac electric mowers, Oleo-Mac trimmers
TR 61 E and TR 91 E, garden tractors. EMAK K-series internal combustion engines powering mowers and
tractors 36 months for consumer use and in other cases 12 months
- Other devices for consumer use 24 months and in other cases 12 months
Additional consumer warranty on Briggs&Stratton engines after the expiration of the manufacturer's warranty period of 12 months -
The condition for maintaining the 36-month warranty period is to perform two paid inspections of the device at an authorized service center - in 12 and 24 month from the date of purchase no later than 7 days after the specified date.
As a condition for maintaining the 60-month warranty period, four paid inspections of the device must be performed at an authorized service center - at 12, 24,36 and 48 months from the date of purchase no later than 7 days after the appointed date. All inspections performed by the dealer must be recorded in the electronic
b2B guarantee settlement system. Internal combustion engines of other brands (Briggs & Stratton, HONDA, KAWASAKI, SUBARU, etc.).) and hydrostatic transmissions are covered by a separate warranty manufacturer. Details of the warranty terms and conditions are contained in separate manuals for the listed components.
2. The warranty covers all damages occurring during the warranty period resulting from the discovery of latent material defects during this period, assembly or technological.
3. The technical staff will proceed with the repair in the time allowed by organizational requirements, always as soon as possible.
4. The choice of how to remove the damage is up to the guarantor, who can remove the defect by repairing the device or replacing the damaged part. Regardless
way of removing the damage, the warranty continues, extended by the time of removal of the damage by the guarantor.
5. Warranty repair can only be carried out on the basis of the device registration in the B2B system or a valid warranty card with proof of purchase.
Failure to register the device, the warranty card or its cancellation will exclude the guarantor's liability under the warranty provided.
6. The user has the right to appeal against the decision of the service point regarding the qualification of the reported failure. The appeal must be submitted only in the form of in writing with a set of documents stating the course of repairs made and a description of the technical condition of the equipment at the time of the original inspection made by the service point.
7. The warranty period is extended by the time necessary for warranty repair. The dates posted on the claim in the b2B electronic guarantee settlement system.
8. The repair shop is required to make entries regarding the scope of warranty repairs in the B2B electronic warranty billing system.
9. For paid repairs performed, the guarantor provides a 3-month warranty on the condition that the repair is carried out in the guarantor's workshop and that the repair is used for the repair original spare parts. The basis for the claim is the proof of purchase of parts and the service performed.
10. Warranty repair is not subject to: damage caused by improper operation, damage caused by using the device for purposes for which it is not intended, damage caused by the use of improper consumables, mechanical damage, and
caused by improper transportation or storage, damage caused by lack of maintenance, components that have suffered wear and tear in service during proper operation.
11. The warranty is voided as a result of structural changes or modifications made by the user, as a result of interference found by the service point
inside the device by unauthorized persons, as a result of breaking or dismantling the carburetor adjustment locks, in the event that entries are found to have been made in the warranty card by unauthorized persons.
12. The warranty does not cover consumable items and items that wear out during the warranty period, such as:
- Consumable components, e.g.: cutting blades, discs, cutting bars, vee heads, filters, starter cables, spark plugs, bulbs, wheels, drums and clutch jaws,
clutches and friction discs, drive belts, safety bolts, cutting chains and guides, high-pressure washer lances.
- Engine components: cylinders, pistons, rings, crankshaft, bearings, pan, carburetor diaphragms.
- Other consumable parts: knife hubs, safety keyways, shock absorbers, bearings, pan, gears, overload fuses, carbon brushes, control ties and cables
- Starting batteries used in machines with an electric starter
- Components not mentioned in these warranty conditions , which obviously wear out during operation, transportation and storage (such as coating painting).
13. Warranty repair does not include installation, adjustment and maintenance activities.
14. Damage such as engine seizure, bent or cracked crankshaft, broken magnet wheel keyway or knife hub are not repairable warranty.
15. If the service center does not fulfill its obligations, the user is obliged to inform the guarantor of this fact. Refusal to comply repair by the service center must be entered in the warranty card. If the guarantor does not recognize the repair as a warranty repair, the cost of repair and transport is covered by the claimant.
16. Defective spare parts replaced under warranty repair are the property of the guarantor.
17. Complaint should be reported to the nearest authorized service center or directly to the guarantor. Reporting a complaint at the point of sale may cause an increase in repair time.
18. During the reception of the device after warranty repair, it is his duty to make sure that the received device is complete and undamaged. The repair point has the obligation to start the device before handing it over to the user after repair.
19. The service point has the right to charge a fee for performing maintenance activities that are the responsibility of the user and require them to be performed before the proceeding with the repair. The repair shop is obliged to replace, at the user's expense, all components that ensure the safety of the work, which have been damaged damage during operation regardless of the consent of the user.
20. A continuously updated list of service points can be found at www.victus.en
21. The warranty for the goods sold does not exclude, limit or suspend the buyer's rights under the warranty provisions for defects in the goods sold.
22. The cost of an unjustified complaint is paid by the complainant.
23. This warranty is valid in the territory of the Republic of Poland.
24. Any damage caused during transport should be immediately reported to the carrier under penalty of voiding the warranty.
25. The warranty does not cover possible damages caused directly or indirectly to persons or things due to defects in the device or resulting from prolonged downtime in the operation of the device.
